* No line voltage, trenching, or metering Immune to power outages
* Battery backup for cloudy days
* Easy to install with quick connect plugs – less than 1 hour
* No scheduled maintenance for up to five years; No cost of replacing concrete, asphalt or landscaping;
No cost of transformers and meters to be added for electric service; No monthly electric bills.
* Controlled charging to prolong battery service life
* Environmentally friendly-100% powered by the sun, solar panels reduce fossil fuel consumption,
eliminating pollution
* Self-contained solution - Light on/off controlled by automatic; daylight sensing or hour preset, no
running and maintenance cost
* Better light source- LED lights feature cool white light without flickering and higher brightness than
sodium lights
* Safe 12 volt/24 volt circuit, no risk of electric shock.
| System Voltage (VDC) | Light Source(W) | Illumination time(H) | Height of lamp(M) | Solar Panel (W) | Battery (A.h) |
|---|---|---|---|---|---|
| 12 | 12 | 10 | 4 | 30 | 38 |
| 15 | 10 | 4 | 40 | 38 | |
| 18 | 10 | 4 | 40 | 50 | |
| 21 | 10 | 4 | 50 | 50 | |
| 24 | 10 | 5 | 60 | 60 | |
| 30 | 10 | 5 | 80 | 80 | |
| 36 | 10 | 6 | 90 | 100 | |
| 42 | 10 | 6 | 100 | 100 | |
| 48 | 10 | 6 | 120 | 120 | |
| 24 | 56 | 10 | 6 | 140 | 140 |
| 63 | 10 | 7 | 160 | 160 | |
| 70 | 10 | 7 | 170 | 160 | |
| 84 | 10 | 8 | 200 | 200 | |
| 98 | 10 | 8 | 240 | 240 | |
| 112 | 10 | 9 | 280 | 300 | |
| 126 | 10 | 10 | 300 | 300 |
Remark:
Solar Panel: 30W-300W monocrystalline or polycrystalline;
Light source: 12W-126W LED or LPS;
Controller: Waterproof IP68, intelligent by time or light control, over-charging and discharging protections;
Storage battery: 20AH-200AH gelled valve-regulated sealed battery for solar lighting;
Light pole: normal 5-10 meters, made of quality steel. Wind resistance ≥120KM/H;
Ambient temperature: -30 ~ +60 centigrade;
Lighting time: 8-12 hours per night, 3-6 overcast or rainy days (as per request);System voltage: DC12V/DC24V.
